| Part No.： | LTC2668 |
| Page： | 30 Pages |
| Size： | 1424 KB |
| Manufacturer： | Linear Technology |
| Logo： |  |
| Views： | 0 |
| Update Time： | 2024-12-24 18:04:22 |
| DataSheet： | Download |
| Part No. | Packing | SPQ | Marking | MSL | Pins | Temp Range | Package Description | Buy |
| LTC2668CUJ-12#PBF | Tube | 61 | 1 | 40 | 0°C ~ 70°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668CUJ-12#TRPBF | Reel | 2000 | 1 | 40 | 0°C ~ 70°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668CUJ-16#PBF | Tube | 61 | 1 | 40 | 0°C ~ 70°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668CUJ-16#TRPBF | Reel | 2000 | 1 | 40 | 0°C ~ 70°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668HUJ-12#PBF | Tube | 61 | 1 | 40 | -40°C ~ 125°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668HUJ-12#TRPBF | Reel | 2000 | 1 | 40 | -40°C ~ 125°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668HUJ-16#PBF | Tube | 61 | 1 | 40 | -40°C ~ 125°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668HUJ-16#TRPBF | Reel | 2000 | 1 | 40 | -40°C ~ 125°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668IUJ-12#PBF | Tube | 61 | 1 | 40 | -40°C ~ 85°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668IUJ-12#TRPBF | Reel | 2000 | 1 | 40 | -40°C ~ 85°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668IUJ-16#PBF | Tube | 61 | 1 | 40 | -40°C ~ 85°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668IUJ-16#TRPBF | Reel | 2000 | 1 | 40 | -40°C ~ 85°C | 40-Lead QFN (6mm x 6mm x 0.75mm) | ||
| LTC2668-12DICE#6AF | Wafflepack | 49 | 1 | 0 | CHIPS OR DIE | |||
| LTC2668-16DICE#6AH | Wafflepack | 49 | 1 | 0 | CHIPS OR DIE |
The LTC2668 is a family of 16-channel, 16-/12-bit ±10V digital-to-analog converters with integrated precision references. They are guaranteed monotonic and have built-in rail-to-rail output buffers. These SoftSpan™ DACs offer five output ranges up to ±10V. The range of each channel is independently programmable, or the part can be hardware-configured for operation in a fixed range.
The integrated 2.5V reference is buffered separately to each channel; an external reference can be used for additional range options. The LTC2668 also includes A/B toggle capability via a dedicated pin or software toggle command.
The SPI/Microwire-compatible 3-wire serial interface operates on logic levels as low as 1.71V at clock rates up to 50MHz.
