| Part No.： | MAX4493 |
| Page： | 15 Pages |
| Size： | 499 KB |
| Manufacturer： | Maxim Integrated |
| Logo： |  |
| Views： | 2 |
| Update Time： | 2023-09-25 14:08:35 |
| DataSheet： | Download |
| Part No. | Packing | SPQ | Marking | MSL | Pins | Temp Range | Package Description | Buy |
| MAX4493AXK+T | Reel | 2500 | 1 | 5 | -40°C ~ 125°C | 5-SC70 | ||
| MAX4493AXK+ | Reel | 2500 | 1 | 6 | -40°C ~ 125°C | 5-SC70 | ||
| MAX4493AXK/V+T | Reel | 2500 | 1 | 7 | -40°C ~ 125°C | 5-SC70 | ||
| MAX4493AXK/V+ | Reel | 2500 | 1 | 8 | -40°C ~ 125°C | 5-SC70 | ||
| MAX4493AUK+T | Reel | 2500 | 1 | 9 | -40°C ~ 125°C | 5-SOT_23 | ||
| MAX4493AUK+ | Reel | 2500 | 1 | 10 | -40°C ~ 125°C | 5-SOT_23 |
The MAX4493 single general-purpose operational amplifiers are designed for use in systems powered with dual supplies from ±2.25V to ±5.5V or with a single supply of +4.5V to +11V. These op amps provide a unity-gain bandwidth of 5MHz with only 770µA of quiescent current per amplifier. The wide input common-mode range extends from 200mV beyond the negative rail to within 1.5V of the positive supply rail while the output swings within 10mV (RL = 100kΩ) of either rail.
These amplifiers have excellent (110dB) open-loop gain with very low THD+N of 0.002% (f = 1kHz). The single MAX4493 is available in a tiny 5-pin SC70 package. The MAX4493 is rated at the automotive temperature range of -40°C to +125°C.
