| Part No.： | LTC3025-3 |
| Page： | 14 Pages |
| Size： | 1558 KB |
| Manufacturer： | Linear Technology |
| Logo： |  |
| Views： | 0 |
| Update Time： | 2025-01-14 14:25:29 |
| DataSheet： | Download |
| Part No. | Packing | SPQ | Marking | MSL | Pins | Temp Range | Package Description | Buy |
| LTC3025EDC-3#TRPBF | Reel | 2500 | LDQS | 1 | 6 | -40°C ~ 125°C | 6-Lead (2mm × 2mm) Plastic DFN | |
| LTC3025EDC-3#TRMPBF | Reel | 500 | LDQS | 1 | 6 | -40°C ~ 125°C | 6-Lead (2mm × 2mm) Plastic DFN | |
| LTC3025IDC-3#TRPBF | Reel | 2500 | LDQS | 1 | 6 | -40°C ~ 125°C | 6-Lead (2mm × 2mm) Plastic DFN | |
| LTC3025IDC-3#TRMPBF | Reel | 500 | LDQS | 1 | 6 | -40°C ~ 125°C | 6-Lead (2mm × 2mm) Plastic DFN |
The LTC3025-3 is a micropower, VLDO™ (very low dropout) linear regulator which operates from input voltages as low as 0.9V. The device is capable of supplying 500mA of output current with a typical dropout voltage of only 85mV. A BIAS supply is required to run the internal reference and LDO circuitry while output current comes directly from the IN supply for high efficiency regulation. The LTC3025-3 have fixed 1.5V output voltages respectively.
The LTC3025-3’s low quiescent current makes it an ideal choice for use in battery-powered systems. For 3-cell NiMH and single cell Li-Ion applications, the BIAS voltage can be supplied directly from the battery while the input can come from a high efficiency buck regulator, providing a high efficiency, low noise output.
Other features include high output voltage accuracy, excellent transient response, stability with ultralow ESR ceramic capacitors as small as 1μF, short-circuit and thermal overload protection and output current limiting. The LTC3025-3 is available in a tiny, low profile (0.75mm) 6-lead DFN (2mm × 2mm) package.
