LT6000 Datasheet

LT6000 Datasheet

Single 1.8V, 13µA Precision Rail-to-Rail Op Amp
Part No.: LT6000
Page: 20 Pages
Size: 260 KB
Manufacturer: Linear Technology
Logo:
Views: 1
Update Time: 2023-11-22 11:43:42
DataSheet: Download

LT6000 Datasheet Applicable Part

Part No. Packing SPQ Marking MSL Pins Temp Range Package Description Buy
LT6000CDCB#PBF Tube   LCDM 1 6 0°C ~ 70°C 6-Lead DFN (2mm x 3mm)
LT6000CDCB#TRPBF Reel 2500 LCDM 1 6 0°C ~ 70°C 6-Lead DFN (2mm x 3mm)
LT6000CDCB#TRMPBF Reel 500 LCDM 1 6 0°C ~ 70°C 6-Lead DFN (2mm x 3mm)
LT6000IDCB#PBF Tube   LCDM 1 6 -40°C ~ 85°C 6-Lead DFN (2mm x 3mm)
LT6000IDCB#TRPBF Reel 2500 LCDM 1 6 -40°C ~ 85°C 6-Lead DFN (2mm x 3mm)
LT6000IDCB#TRMPBF Reel 500 LCDM 1 6 -40°C ~ 85°C 6-Lead DFN (2mm x 3mm)
SPQ:Standard Pack Quantity;MSL:Moisture Sensitivity Level

LT6000 Datasheet(PDF)

LT6000 Datasheet(Picture)

LT6000 Features

  • Ideal for Battery-Powered Applications
    • Low Voltage: 1.8V to 16V Operation
    • Low Current: 16µA/Amplifier Max
    • Small Packages: DFN, MSOP, SSOP
    • Shutdown to 1.5µA Max (LT6000,)
  • Low Offset Voltage: 600µV Max
  • Rail-to-Rail Input and Output
  • Fully Specified on 1.8V and 5V Supplies
  • Operating Temperature Range: –40°C to 85°C
  • Single Available in DFN

LT6000 Applications

  • Gas Sensing
  • Portable Instrumentation
  • Battery- or Solar-Powered Systems
  • Low Voltage Signal Processing
  • Micropower Active Filters

LT6000 Description

The LT6000 are single precision rail-to-rail input and output operational amplifiers. Designed to maximize battery life in always-on applications, the devices will operate on supplies down to 1.8V while drawing only 13µA quiescient current. The low supply current and low voltage operation is combined with precision specifications; input offset is guaranteed less than 600µV. The performance on 1.8V supplies is fully specified and guaranteed over temperature. A shutdown feature available in the LT6000 and the 10-lead dual LT6001 version can be used to extend battery life by allowing the amplifiers to be switched off during periods of inactivity.

The LT6000 is available in a tiny, dual fine pitch leadless DFN package. The LT6000 are specified over the commercial and industrial temperature range.
