| Part No.： | LT1610 |
| Page： | 16 Pages |
| Size： | 198 KB |
| Manufacturer： | Linear Technology |
| Logo： |  |
| Views： | 2 |
| Update Time： | 2023-12-19 14:54:48 |
| DataSheet： | Download |
| Part No. | Packing | SPQ | Marking | MSL | Pins | Temp Range | Package Description | Buy |
| LT1610CMS8#PBF | Tube | 50 | LTDT | 1 | 8 | 0°C ~ 70°C | 8-Lead MSOP | |
| LT1610CMS8#TRPBF | Reel | 2500 | LTDT | 1 | 8 | 0°C ~ 70°C | 8-Lead MSOP | |
| LT1610CMS8#TRMPBF | Reel | 500 | LTDT | 1 | 8 | 0°C ~ 70°C | 8-Lead MSOP | |
| LT1610CS8#PBF | Tube | 100 | 1610 | 1 | 8 | 0°C ~ 70°C | 8-Lead SOIC | |
| LT1610CS8#TRPBF | Reel | 2500 | 1610 | 1 | 8 | 0°C ~ 70°C | 8-Lead SOIC | |
| LT1610CS8#TRMPBF | Reel | 500 | 1610 | 1 | 8 | 0°C ~ 70°C | 8-Lead SOIC | |
| LT1610IS8#PBF | Tube | 100 | 1610I | 1 | 8 | -40°C ~ 125°C | 8-Lead SOIC | |
| LT1610IS8#TRPBF | Reel | 2500 | 1610I | 1 | 8 | -40°C ~ 125°C | 8-Lead SOIC | |
| LT1610IS8#TRMPBF | Reel | 500 | 1610I | 1 | 8 | -40°C ~ 125°C | 8-Lead SOIC |
The LT1610 is a micropower fixed frequency DC/DC converter that operates from an input voltage as low as 1V. Intended for small, low power applications, it switches at 1.7MHz, allowing the use of tiny capacitors and inductors.
The device can generate 3V at 30mA from a single cell (1V) supply. An internal compensation network can be connected to the LT1610’s VC pin, eliminating two external components. No-load quiescent current of the LT1610 is 30µA, and the internal NPN power switch handles a 300mA current with a voltage drop of 300mV.
The LT1610 is available in 8-lead MSOP and SO packages.
