| Part No.： | ADF4113 |
| Page： | 28 Pages |
| Size： | 388 KB |
| Manufacturer： | Analog Devices, Inc. |
| Logo： |  |
| Views： | 0 |
| Update Time： | 2025-01-17 17:53:31 |
| DataSheet： | Download |
| Part No. | Packing | SPQ | Marking | MSL | Pins | Temp Range | Package Description | Buy |
| ADF4113BCPZ | Tray | 490 | ADF4113BCPZ | 3 | 20 | -40°C ~ 85°C | 20-Lead LFCSP_WQ | |
| ADF4113BCPZ-RL | Reel | ADF4113BCPZ | 3 | 20 | -40°C ~ 85°C | 20-Lead LFCSP_WQ | ||
| ADF4113BCPZ-RL7 | Reel | 1500 | ADF4113BCPZ | 3 | 20 | -40°C ~ 85°C | 20-Lead LFCSP_WQ | |
| ADF4113BRU | Tube | 96 | ADF4113B | 1 | 16 | -40°C ~ 85°C | 16-Lead TSSOP | |
| ADF4113BRU-REEL7 | Reel | 1000 | ADF4113B | 1 | 16 | -40°C ~ 85°C | 16-Lead TSSOP | |
| ADF4113BRUZ | Tube | 96 | ADF4113B | 1 | 16 | -40°C ~ 85°C | 16-Lead TSSOP | |
| ADF4113BRUZ-REEL | Reel | 2500 | ADF4113B | 1 | 16 | -40°C ~ 85°C | 16-Lead TSSOP | |
| ADF4113BRUZ-REEL7 | Reel | 1000 | ADF4113B | 1 | 16 | -40°C ~ 85°C | 16-Lead TSSOP |
The ADF4113 family of frequency synthesizers can be used to implement local oscillators in the up-conversion and down-conversion sections of wireless receivers and transmitters. They consist of low-noise digital PFD (Phase Frequency Detector), a precision charge pump, a programmable reference divider, programmable A and B counters and a dual modulus prescaler (P/P+1). The A (6-bit) and B (13-bit) counters, in conjunction with the dual modulus prescaler (P/P+1), implement an N divider (N = BP+A).
In addition, the 14-bit reference counter (R Counter), allows selectable REFIN frequencies at the PFD input. A complete PLL (Phase-Locked Loop) can be implemented if the synthesizer is used with an external loop filter and VCO (Voltage Controlled Oscillator).
Control of all the on-chip registers is via a simple 3-wire interface. The devices operate with a power supply ranging from 2.7 V to 5.5 V and can be powered down when not in use.
